Chapter 4
Configuration via the Command Line Interface
E-DOC-CTC-20051017-0169 v0.1
136
4.6.1 Network Descriptor Parameters
Parameters table The following table summarizes the parameters comprised in the Network
Descriptor:
Network name [name] This name is used internally to identify the Network Descriptor.
Type of network and IP
address [type] and [ip]
The type and ip parameters locate the network in the IP address space.
For ip, enter a value corresponding to the network type.
Parameter Keyword Description
Network name name
Mandatory. Symbolic name to identify the
network.
Type type
Mandatory. A network can either be:
a single IP address
an IP subnet
an IP address range
IP address ip Mandatory. The IP address of the network
Protocol proto
Optional. The communication protocol allowed on
the secure network
Port port
Optional. For UDP and TCP, the port number that is
allowed to use the secure network.
type ip
Valid network types
are:
Keyword: Examples:
a single IP address address
10.0.0.15
a single IP subnet subnet
10.0.0.0/24
a contiguous IP address
range
range
10.0.0.5-10.0.0.56
10.0.0.[5-56]
