Chapter 4
Configuration via the Command Line Interface
E-DOC-CTC-20051017-0169 v0.1
106
4.2.2 List all Authentication Attributes
list command The ipsec peer auth list command shows all previously created
authentication attributes.
Example In this example, four attributes are shown:
cert1: completely defined authentication attribute using certificates
secret2: created, but not yet completely configured
secret1: completely defined authentication attribute using pre-shared key.
[ipsec]=>
[ipsec]=>peer
[ipsec peer]=>auth
[ipsec peer auth]=>list
[cert1]
Authtype : cert
[secret2]
Authtype : <unset>
[secret1]
Authtype : preshared
Secret : ********
[ipsec peer auth]=>
