605
Nortel WLAN Security Switch 2300 Series Configuration Guide
Appendix C: Mobility Domain
Traffic Ports
When deploying a Mobility Domain, you might attach the WSS switches to subnets that have firewalls or access
controls between them. Within a Mobility Domain, WSS switches exchange information and other types of traffic,
depending on your configuration of AAA and various management services.
Table 41 lists the traffic ports typically used by a Mobility Domain and its associated AAA and management functions.
The traffic typically sent between WSS switches within a Mobility Domain uses IP/UDP protocol 17 traffic on port 8817
for both source and destination. Roaming traffic uses IP protocol 4.
Table 41: Traffic Ports for AAA Servers and Management Servers
Protocol Port Function
IP/UDP (17) 1812 RADIUS authentication (default setting)
IP/UDP (17) 1813 RADIUS accounting (default setting)
IP/TCP (6) 443 SSL management through Web View
IP/TCP (6) 8889 SSL management through WMS
IP/TCP (6) 23 Telnet management
IP/UDP (17) 161 SNMP get and set operations
IP/UDP (17) 162 SNMP traps
IP/ICMP (1) N/A Several types (for example, ping)
IP/UDP (17) 123 NTP
IP/UDP (17) 53 DNS
