Managing Keys and Certificates 381
Nortel WLAN Security Switch 2300 Series Configuration Guide
PEAP-MS-CHAP-V2 Security
PEAP performs a TLS exchange for server authentication and allows a secondary authentication to be performed inside
the resulting secure channel for client authentication. For example, the Microsoft Challenge Handshake Authentication
Protocol version 2 (MS-CHAP-V2) performs mutual MS-CHAP-V2 authentication inside an encrypted TLS channel
established by PEAP.
1 To form the encrypted TLS channel, the WSS must have a digital certificate and must send that certificate
to the wireless client.
2 Inside the WSS switch’s digital certificate is the WSS’s public key, which the wireless client uses to
encrypt a pre-master secret key.
3 The wireless client then sends the key back to the WSS so that both the WSS and the client can derive a
key from this pre-master secret for secure authentication and wireless session encryption.
Clients authenticated by PEAP need a certificate in the WSS only when the switch performs PEAP locally, not when
EAP processing takes place on a RADIUS server. (For details about authentication options, see Chapter , “Configuring
AAA for Network Users,” on page 401.)
About Keys and Certificates
Public-private key pairs and digital signatures and certificates allow keys to be generated dynamically so that data can be
securely encrypted and delivered. You generate the key pairs and certificates on the WSS or install them on the switch
after enrolling with a certificate authority (CA). The WSS can generate key pairs, self-signed certificates, and Certificate
Signing Requests (CSRs), and can install key pairs, server certificates, and certificates generated by a CA.
When the WSS needs to communicate with WLAN Management Software , Web View, or an 802.1X or Web-based
AAA client, WSS Software requests a private key from the switch’s certificate and key store:
• If no private key is available in the WSS’s certificate and key store, the switch does not respond to the request from
WSS Software. If the switch does have a private key in its key store, WSS Software requests a corresponding
certificate.
• If the WSS has a self-signed certificate in its certificate and key store, the switch responds to the request from WSS
Software. If the certificate is not self-signed, the switch looks for a CA’s certificate with which to validate the
server certificate.
• If the WSS has no corresponding CA certificate, the switch does not respond to the request from WSS Software. If
the switch does have a corresponding CA certificate, and the server certificate is validated (date still valid, signature
approved), the switch responds.
If the WSS switch does not respond to the request from WSS Software, authentication fails and access is denied.
For EAP (802.1X) users, the public-private key pairs and digital certificates can be stored on a RADIUS server. In this
case, the WSS switch operates as a pass-through authenticator.
Note. The WSS uses separate server certificates for Admin, EAP (802.1X), and
Web AAA authentication. Where applicable, the manuals refer to these server certificates
as Admin, EAP (or 802.1X), or Web AAA certificates respectively.
