Configuring AP access points 233
Nortel WLAN Security Switch 2300 Series Configuration Guide
● If the DHCP Ack message contained a list of WSS hostnames in DHCP option 43, the AP sends
DNS Requests to the DNS server for the IP addresses of the switches, then sends a unicast Find
WSS message to each address. The process continues with step 8.
● If no WSS switches reply, the AP resends the Find WSS messages up to 11 more times. If no WSSs
reply after all 12 attempts, the AP tries to find an WSS switch using the DNS server. The process
continues with step 5.
5 If the AP is unable to locate an WSS on the subnet it is connected to, and is unable to find an WSS based
on DHCP option 43, the AP sends DNS requests to both NORTEL and wlan-switch, where the DNS
suffix for mynetwork.com is learned through DHCP.
6 The DNS server replies with the system IP address of an WSS switch.
● If only NORTEL is defined in DNS, the AP sends a unicast Find WSS message to the WSS switch
whose IP address is returned for NORTEL.
● If only wlan-switch is defined in DNS, the AP sends a unicast Find WSS message to the WSS switch
whose IP address is returned for wlan-switch.
● If both NORTEL and wlan-switch are defined in DNS, the AP sends a unicast Find WSS message to
the WSS switch whose IP address is returned for NORTEL. The AP ignores the IP address returned
for wlan-switch.
● If both NORTEL and wlan-switch are defined in DNS, and the AP is unable to contact the IP address
returned for NORTEL, the AP never contacts the IP address returned for wlan-switch. The AP does
not boot.
7 The AP sends Find WSS requests to the WSS IP addresses given by the DNS reply. If an WSS receives
the Find WSS Request, the process continues with step 8.
However, if no WSS switches reply, the AP retries this method up to 11 more times:
● If no WSSs reply after all 12 attempts, the AP begins the process again with step 1 on the other AP
port.
● If the other AP port does not have a link or the AP has only one port, the AP instead restarts, and
begins the process again with step 1 on the same AP port.
8 The WSS that receives the Find WSS request determines the best WSS for the AP to use, based on the
bias settings for the AP on each switch. If more than one switch has high bias for the AP or all switches
have the same bias, the WSS suggests the switch that has the highest capacity to add new active AP
connections.
9 The WSS sends a unicast Find WSS Reply message to the AP containing the system IP address of the
best WSS switch to use.
10 The AP sends a unicast message to the suggested WSS switch, to request a software image and
configuration. If the AP does not receive a reply after 10 seconds, the AP reboots and starts the boot
process over at step 1.
Note. This method requires DNS address records on the DNS server that map
the hostnames to the WSS IP addresses.
Note. You must configure a DNS address record on your DNS server for the
WSS IP address. Otherwise, the DNS server cannot provide the WSS switch’s
address to the AP.
