230 Configuring AP access points
320657-A
Dual-Homed Distributed Connections to WSSs on Both AP Ports
Figure 10 shows an example of a dual-homed configuration in which both AP connections are distributed over
the network.
Figure 10. Dual-homed Distributed Connections to WSSs on Both AP
Ports
In this configuration, the AP first attempts to boot on its port 1. If more than one WSS has high bias or if all
WSSs have the same bias, the AP uses the WSS that has the greatest capacity for new active AP connections.
AP port 1
Network
backbone
WSS
WSS
WSS
AP port 2
Network
backbone
