210 Configuring User Encryption
320657-A
This section describes how to configure and assign static WEP keys. (To change other key-related settings, see
“Managing 802.1X Encryption Keys” on page 491.)
Figure 5 shows an example of a radio configured to provide static and dynamic WEP encryption for non-WPA clients.
The radio uses dynamically generated keys to encrypt traffic for dynamic WEP clients. The radio also encrypts traffic for
static WEP clients whose keys match the keys configured on the radio.
Figure 5. Encryption for Dynamic and Static WEP
WLAN Security Switch
User D
TKIP
WPA
User C
Static WEP
-Unicast key = a1b1c1d1e1
-Multicast key = a2b2c2d2e2
Non-WPA
User B
Dynamic 40-bit WEP
WPA
User A
Dynamic WEP
Non-WPA
8
40-9502-0029
WPA disabled
Dynamic WEP enabled
Static WEP enabled
-Unicast key = a1b1c1d1e1
-Multicast key = a2b2c2d2e2
