206 Configuring User Encryption
320657-A
Displaying WPA Settings
To display the WPA settings in a service profile, use the following command:
show service-profile {name | ?}
To display the WPA settings in effect in service profile wpa, type the following command:
23x0# show service-profile wpa
ssid-name: private ssid-type: crypto
beacon: yes auth-fallthru: last-resort
WEP Key 1 value: <none> WEP Key 2 value: <none>
WEP Key 3 value: <none> WEP Key 4 value: <none>
WEP Unicast Index: 1 WEP Multicast Index: 1
Shared Key Auth: NO
WPA enabled:
ciphers: cipher-tkip, cipher-wep40
authentication: 802.1X
TKIP countermeasures time: 30000ms
The WPA settings appear at the bottom of the output.
Assigning the Service Profile to Radios and Enabling the Radios
After you configure WPA settings in a service profile, you can map the service profile to a radio profile, assign the radio
profile to radios, and enable the radios to activate the settings.
To map a service profile to a radio profile, use the following command:
set radio-profile name service-profile name
To assign a radio profile to radios and enable the radios, use the following command:
set ap port-list radio {1 | 2} radio-profile name mode {enable | disable}
To map service profile wpa to radio profile bldg1, type the following command:
23x0# set radio-profile blgd1 service-profile wpa
success: change accepted.
To assign radio profile bldg1 to radio 1 on ports 5-8, 11-14, and 16 and enable the radios, type the following command:
23x0# set ap 5-8,11-14,16 radio 1 radio-profile bldg1 mode enable
success: change accepted.
To assign radio profile bldg1 to radio 2 on ports 11-14 and port 16 and enable the radios, type the following command:
23x0# set ap 11-14,16 radio 2 radio-profile bldg1 mode enable
success: change accepted.
Note. The WPA fields appear in the show service-profile output only when WPA is
enabled.
