4.2.18 S2F15 - New Equipment Constant Send
S2F15 W * H->E
<L
<L [2]
<U4 VID> * Equipment Constant ID
<V>
>
...
> .
The Host sends new values for desired equipment constants. Several equipment constants can be specified
if desired.
Only VIDs of class EC can be used in this message.
4.2.19 S2F16 - Equipment Constant Send Acknowledge
S2F16 * H<-E
<B [1] EAC> . * Equipment Acknowledge Code
Normal completion returns a zero (0) in EAC. If any ECID or ECV in S2F15 is invalid, then EAC
contains a non-zero value, and the Equipment rejects the entire S2F15.
Table 4-4 EAC Values
EAC Description
0x00 OK.
0x01 At least one ECID is invalid.
0x03 At least one ECV is out of range.
4-12 Equipment-to-Host Messages
