4.1.2 Message Format
The format of a complete message is as follows:
SnFn W item .
The components of a complete message are described in Table 4-2.
Table 4-2 Components SML Notation
Component Description
SnFn
The Stream and Function Codes, S1F1 for example.
W
The W-Bit, if set. Omitted if not set. If the W-Bit is optional, it is coded within brackets
“[W]”.
item
A Data Item that is formatted as described in 4.1.1.
.
A period (.) ends the message definition.
For example, the S1F3 message might be described in SML as follows:
S1F3 W
<L
<U4 13>
<U4 7>
> .
Equipment-to-Host Messages 4-3
