Equipment-to-Host Messages 3-41
3.12.3 Spool States
3.12.3.1 Power Off
The Equipment is completely shut down.
3.12.3.2 Power On
The Equipment is “on” and in a stable state. Table 3-26 describes the substates.
Table 3-26 Power On Spool Substates
Substate Description
Spool
Inactive
Spooling is not activated. This is either because GemConfigSpool is “0” (disabled) in
which case, spooling will never be active, or because while GemConfigSpool is
enabled (“1”), a RTY error has not occurred. In this state, no messages are sent to the
spool. The Host may define or un-define messages eligible for spooling should the link
go down.
Spool
Active
While GemConfigSpool is enabled (“1”), the Equipment has experienced a
transmission failure (RTY error). Upon entry into this state, the first message sent to
the spool is the GemSpoolingActivated event, assuming that this event is enabled and
that spooling for the particular stream and function have been enabled. This message
will enter the spool even before the message which originally caused the RTY error.
Spool Not Full
- The file containing the spooled messages has not reached its
capacity.
Spool Full - The file containing the spooled messages has reached its capacity.
No Spool Output
- In this state, the Host is not reading or purging the Equipment’s
spool.
Spool Output
- This super-state contains the two sub-states in which the Equipment’s
spool is either being read or purged by the Host.
Purge Spool
- The Equipment is purging its spool, erasing all spooled messages.
Transmit Spool
- The Equipment is transmitting spooled messages to the Host.
