Equipment-to-Host Messages 3-15
3.3.1.2 E10 STATE Values
The values for E10 states are listed in Table 3-10.
Table 3-10 E10 State Values
Value Description
Non-Productive/Non-
Scheduled Time
The Equipment is not scheduled to be used in production. An
Operator can put the Equipment into this state at any time.
Non-Productive/Unscheduled
Downtime
The Equipment has been scheduled to be used in production, but is
unable to be used because of unforeseen events. Possible reasons
for transitions into this state include:
1) maintenance delay
2) repair
3) replacement of a disposable
4) bad input (bad boards, etc.)
5) facility related downtime
Non-Productive/Scheduled
Downtime
The Equipment has been scheduled to be out of production so that
maintenance can be performed.
Non-Productive/Engineering The Equipment may be actively running boards, but these are not
intended to be used in normal production. This state signifies that
Engineering data is being gathered from the Equipment separate
from an actual productive run.
Non-Productive/Standby The Equipment is ready for production, but is awaiting resources.
These resources may be in the form of physical material (boards)
or in the form of information (process program, and START
command).
Productive The Equipment is actively processing boards for use in production.
