3-14 Equipment-to-Host Messages
3.3.1.1 E10 State Transitions
Certain state transitions will cause a collection event to be signaled. If the event is enabled, this event will
be sent to the Host along with the appropriate reports if appropriate. Table 3-9 lists the state transitions
and notes when events will be sent to the Host.
"
NOTE The numbers in the # column refer to those in Figure 3-3.
Table 3-9 E10 State Transitions
# From Trigger To Description
1 Unknown Power-Up Non-
Scheduled
Time
Upon Power-Up, the Equipment defaults
to this state.
2 Unknown Operator
Request
Conditional The Operator changes states from the
previous state to the new state. The
conditional depends on the Operator’s
intentions.
3 Non-
Productive
Operator
Request
Non-
Productive
–
4 Standby Processing
of material
begins.
Productive Equipment is processing material.
5 Productive Operator
Request
Non-
Productive
The Operator changes states from
Productive to a new Non-Productive state.
Transition will be made according to
conditional transition #2.
