1
2
4
3
5
Item Name Description
1 Incoming
Message
Messages from the Host are displayed in this box.
2 Acknowledge Press to acknowledge receipt of the incoming message from the Host.
3 Outgoing
Message
Enter messages to the Host in this box.
4 Send Press to send the message in the Outgoing Message box.
5 Status Box Displays the current communication state, control state, and spooling state.
Figure 1-3 SECS/GEM Setup Dialog Box – Terminal Tab
1-20 Equipment-to-Host Messages
