Remote run commands are described in Table 1-7.
Table 1-7 Remote Run Commands
Command Description
START This command is successful when the Control State is OnLine - REMOTE , the board
is in the Dispensing position, the machine is configured for a run, and the process
program has been selected. This event begins the continuous processing of substrate
trays. Processing can be interrupted by STOP, PAUSE, and ABORT commands. The
Operator can also initiate PAUSE and STOP commands from the Run Window.
STOP This command is successful when the Control State is OnLine - REMOTE, and the
Process State is Running. It causes a halt in dispensing following completion of the
current substrate cycle. The Process State changes to IDLE when this command is
delivered and the process program is terminated. Further processing of the substrate
tray is not possible after completing this command.
PAUSE This command is successful when the Control State is OnLine - REMOTE and the
Process State is Running. It causes a halt in dispensing following completion of the
current instruction. The board and the process program are retained without change.
The Process State changes to PAUSED. Diagnostics and status checks may be
performed at this time. The substrate processing may be continued in the Running
State by delivering the RESUME command.
RESUME This command is successful when the Control State is OnLine - REMOTE, and the
Process State is PAUSED. Processing of the substrate tray continues exactly from the
PAUSED point and the current process program executes from the beginning of the
next unprocessed instruction.
LOCAL This command is successful if the current Control State is OnLine -REMOTE,
otherwise it is ignored. The Host may request local operation for an Operator to
perform maintenance or inspection of the machine. The Host may request a return to
operation under its command by delivering the REMOTE command.
REMOTE This command is successful if the current Control State is OnLine - LOCAL, the
Process State is IDLE and the configuration allows remote operation. Return to the
REMOTE state following an ALARM or ABORT command without proper Operator
inspection and delivery of a Proceed event may return the machine to the same error
state which initially caused the machine to leave the REMOTE state.
ABORT This command is successful if the current Control State is OnLine - REMOTE, the
Process State is Running, and the configuration allows remote operation. This
command indicates an error status which prevents further dispensing operation until
the error is corrected. Dispensing is immediately stopped and the current process
program is terminated. Operator intervention and maintenance is generally required in
order to resume operation past this point
1.11.6.3 Material Movement
FmNT declares two material movement events. The event notifications to the Host are: Dispensing and
DispensingDone.
Movement of the board into the ready position for dispensing invokes the Dispensing event. Transfer of
the board out of the ready position after dispensing invokes the DispensingDone event.
