Table B-1 CEID (continued)
CEID Name Description
Setup
4001 PromptedSetupStarted An operator has initiated the Prompted Setup process.
4002 PromptedSetupCompleted The Prompted Setup Process is completed.
4003 FindNeedleXYZ An automatic needle XYZ calibration has been performed.
4004 ManualMeasureFlowRate1 A flow rate measurement for Valve 1 has been initiated by an
operator.
4005 ManualPurgeNeedle1 A needle purging of Valve 1 has been initiated by an operator.
4006 OperationLevelChanged The system operation level has been changed.
4007 PasswordsModified The system operation level passwords have been modified.
4008 ManualMeasureFlowRate2 A flow rate measurement for Valve 2 has been initiated by an
operator.
4009 ManualPurgeNeedle2 A needle purging of Valve 2 has been initiated by an operator.
4010 ScaleRead1 The Scale has been read after Valve 1 has dispensed material
during the Flow Rate Verification Procedure. Data Variable
ScaleMeasurement1 holds the scale measurement.
4011 ScaleRead2 The Scale has been read after Valve 2 has dispensed material
during the Flow Rate Verification Procedure. Data Variable
ScaleMeasurement2 holds the scale measurement.
4012 FlowRate1Updated The Flow Rate for Valve 1 has been updated (Data Variable
FlowRate1 has been modified).
4013 FlowRate2Updated The Flow Rate for Valve 2 has been updated (Data Variable
FlowRate2 has been modified).
Run Time
5001 HeaterMonitorTimeout The heaters at the dispensing location failed to reach the
specified temperature range within the timeout period.
5002 HeaterMonitorSkipped The Operator has selected to skip the temperature monitoring
and proceed to dispensing.
5003 HeaterMonitorAborted The Operator has selected to abort the temperature monitoring
and aborted the run.
5004 PeriodicPurge1 A periodical purging of the needle for Valve 1 has been
performed.
Appendix B – Collection Events B-3
