Owner's manual

Table B-1 CEID (continued)
CEID Name Description
Board Handling
2001 BoardAtDispenseLoc1 The board is at the dispensing location for Conveyor 1 and ready
for dispensing.
2002 DispensingDone1 Dispensing is completed for Conveyor 1. The board is ready to
leave the dispensing location.
2003 BoardAtDispenseLoc2 The board is at the dispensing location for Conveyor 2 and ready
for dispensing.
2004 DispensingDone2 Dispensing is completed for Conveyor 2. The board is ready to
leave the dispensing location.
2050 BarcodeRead Sent to the host after a barcode has been successfully read.
This event will occur after events BoardAtDispenseLoc1 and
BoardAtDispenseLoc2.
2051 MachineEmpty Sent to the host when the machine has set idle waiting for a
board after a user configurable timeout.
File Handling
3001 NewProgramLoaded A new program is loaded.
3002 NewFluidFileLoaded1 A new fluid parameter file for Valve 1 is loaded.
3003 NewHeaterFileLoaded A new heater parameter file is loaded.
3004 FluidParametersModified1 The fluid parameters for Valve 1 have been changed by an
operator.
3005 FluidParametersSaved1 The fluid parameters for Valve 1 have been saved onto the local
mass storage.
3008 ConveyorCodeDownloaded1 A new conveyor control code has been downloaded into the
Conveyor 1 controller.
3009 NewFluidFileLoaded2 A new fluid parameter file for Valve 2 is loaded by an operator.
3010 FluidParametersModified2 The fluid parameters for Valve 2 have been changed by an
operator.
3011 FluidParametersSaved2 The fluid parameters for Valve 2 have been saved onto the local
mass storage.
3012
ConveyorCodeDownloaded2 A new conveyor control code has been downloaded into the
Conveyor 2 controller.
B-2 Appendix B – Collection Events
