Appendix B – Collection Events
Table B-1 lists the collection events that exist at the Equipment.
Table B-1 CEID
CEID Name Description
Note: CEID 1 – 65 are standard GEM
1 ControlStateChange Event is triggered when there is a change in control state.
2 ProcessStateChange Event is triggered when there is a change in process state.
3 GemPPChangeEvent Event is triggered when the Operator creates, changes, or
deletes a process program.
4 OperatorCommand Sent whenever the Operator attempts to control the machine
while in the Online - REMOTE state.
5 AbortStarted Event is triggered when an abort request was acknowledged and
the abort process begins.
6 AbortCompleted Event is triggered when the abort process is complete.
7 GemBadDownloadEvent After the host downloads a recipe to the equipment upon the
equipment’s request, the equipment checks the recipe for
accuracy. If the process program is invalid, event is triggered.
8 GemControlStateLOCAL Sent when Control State changes to LOCAL.
9 GemControlStateREMOTE Sent when Control State changes to REMOTE.
14 StartCmd Sent when the Operator clicks the GO button from Teach
Window or Run Window.
15 StopCmd Sent when the Operator clicks the STOP button from Teach
Window or Run Window.
16 PauseCmd Sent when the Operator clicks the PAUSE button from Teach
Window or Run Window and the equipment is in RUNNING
state.
17 ResumeCmd Sent when the Operator clicks the PAUSE button from Teach
Window or Run Window and the equipment is in PAUSED state.
18 AbortCmd Sent when the Operator clicks the ABORT button from Teach
Window or Run Window.
20 EqConstChange Sent to the Host when the Operator changes an Equipment
Constant.
21 S10Ack Sent to acknowledge the reception of a Host text message.
22 GemEquipmentOFFLINE Sent when Control State changes to Off-Line.
23 GemSpoolingActivated Sent when Equipment attempts to send a primary message to
the Host and gets a transmit failure while Spooling is enabled.
24 GemSpoolingDeactivated Sent after the entire spool file has been read by the Host.
25 GemSpoolTransmitFailure Sent if a transmission failure occurs during the period in which
the Host is reading the Spooling file.
