Appendix A – Data Dictionary Values A-5
Table A-1 Data Dictionary Variables (continued)
VID Class Format Name and Description
43 EC U1 ONLINEFAILED. The default Control State transition when Attempt On-
Line fails.
1 = Equipment Off-Line
2 = Host Off-Line
44 EC U1 ONLINESUBSTATE. The default (power-up) online substate of the
Control State Model.
4 = Local
5 = Remote
46 EC U4 MAXSPOOLTRANSMIT. The maximum number of spooled messages
the equipment will send each time the Host reads the spool. A setting of
zero indicates that all spooled messages should be sent. Refer to the
description of S6F23 in the "SECS Message Detail" section for further
information.
48 SV U4 SPOOLCOUNTACTUAL. A count of the number of messages actually
present on the spool disk, adjusted for any messages which have been
overwritten or otherwise discarded.
49 SV U4 SPOOLCOUNTTOTAL. A count of the number of messages the
equipment attempted to write to the spool disk. This number includes
messages actually present on the spool disk, and also any messages
which may have been overwritten or otherwise discarded.
50 SV A[16] SPOOLFULLTIME. The date and time at which the spool file became full.
Format is: YYYYMMDDhhmmsscc. See description of CLOCK variable
(VID 27) above for format details.
51 SV U4 SPOOLLOADSUBSTATE. The current state within the SPOOL LOAD
super-state.
6 = Spool Not Full
7 = Spool Full
52 SV A[16] SPOOLSTARTTIME. The date and time at which the first message was
written to the current spool file. Format is: YYYYMMDDhhmmsscc.
See description of CLOCK variable (VID 27)above for format details.
53 SV U4 SPOOLSTATE. The current spool state within the POWER ON super-
state.
1 = Spool Active
2 = Spool Inactive
54 SV U4 SPOOLUNLOADSUBSTATE. The current spool state within the SPOOL
UNLOAD super-state.
3 = Purge Spool
4 = Transmit Spool
5 = No Spool Output
