Table 8-1 Equipment-to-Host Messages (continued)
Primary Reply Description Notes
S6F13 S6F14 Annotated Event Report Send GemNoteEvent
Possible variable access
routines.
N
S7F1 S7F2 Process Program Inquire/Grant GemUFPPSend or
GEMFPPSend
S7F3
S7F4
*
Unformatted Process Program Send GemUFPPSend
Disk Read occurs
S7F5 S7F6 Unformatted Process Program Request GemUFPPLoad
UFPPVerify
Disk write occurs.
S9F1 -- Error, Device ID None
S9F3 -- Error, Stream None
S9F5 -- Error, Function None
S9F7 -- Error, Data None
S9F9 -- Error, Transaction Timeout None
S9F11 -- Error, Data Too Long None
S9F13 -- Error, Conversation timeout Sent by application only if
required.
S10F1 S10F2 Terminal Request GemTerminalRequest
S13F1 S13F2 Send Data Set Send GemDSNameSend
8-2 Equipment-to-Host Messages
