8. Equipment-to-Host Messages
"
NOTE In Table 8-1 “Reply” column:
*
= FmNT secondary message handlers
Table 8-1 Equipment-to-Host Messages
Primary Reply Description Notes
-- (any) SnF0 Primary rejected while Off-Line None
S1F1 S1F2 Are You There None (heartbeat)
GemGoAOnline
(Attempt Online)
S1F13 S1F14 Connect Request None
S1F65 S1F66 Connect Request None
N
S2F17 S2F18 Date and Time Request GemHostTimeReq
S5F1
S5F2
*
Alarm Report GemNoteAlarmEvent
N
S5F71 S5F72 Alarm Report Block Send GemNoteAlarmEvent
S5F73 S7F74 Alarm Notification Send GemNoteAlarmEvent
S6F1 S6F2 Trace Data Send Possible variable access
routines.
S6F3 S6F4 Annotated Event Report Send GemNoteEvent
Possible variable access
routines.
N
S6F5 S6F6 Multi-Block Data Send Inquire/Grant None
S6F9 S6F10 Event Report Send GemNoteEvent
Possible variable access
routines.
N
S6F11 S6F12 Event Report Send GemNoteEvent
Possible variable access
routines.
Equipment-to-Host Messages 8-1
