7. Host-to-Equipment Messages
"
NOTE In Table 7-1 “Primary” and “Reply” columns:
*
= FmNT secondary message handlers
**
= FmNT primary message handlers
Table 7-1 Host-to-Equipment Messages
Primary Reply Cstate Description Notes
S1F1 S1F2 4,5 Are You There None
S1F3 S1F4 4,5 Selected Status Possible variable access
S1F11 S1F12 4,5 Status Variable Namelist
Request
None
S1F13 S1F14 All Connect Request None
S1F15
S1F16
*
4,5 Request Off-Line None
S1F17
S1F18
*
1,2,3 Request On-Line None
S1F65
S1F66
*
All Connect Request None
N
S2F13 S2F14 4,5 Equipment Constant Request Possible variable access
(only if non-ECs requested).
S2F15
S2F16
*
4,5 New Equipment Constant
Send
Possible EC validation
routines.
EC-Changed processing
routine. Disk write occurs.
S2F17
S2F18
*
4,5 Date and Time Request None
S2F21 S2F22 5 Remote Command Primary message handler
N ( for Non GEM Hosts ).
S2F23 S2F24 4,5 Trace Initialize None
S2F25 S2F26 4,5 Loopback Diagnostic None
E
S2F27
S2F28
*
5 Initiate Processing Request Primary Message Handler
N
S2F29**
S2F30 4,5 Equipment Constant
Namelist Request
None
E
Host-to-Equipment Messages 7-1
