Machine Variable Definitions 6-7
Table 6-3 Equipment Constants (continued)
Variable Name ID Storage
Type
Description
MeasFlowEnabled 601 BOOL This Boolean flag indicates whether periodic flow rate
calibration operations are enabled.
1 - Enabled
0 - Disabled
OFFLINESUBSTATE 42 U1 This variable determines the Control State that the
Equipment enters when it enters the OffLine super-
state. The allowable values are:
1 - Equipment Off-Line
2 - Attempt On-Line
3 - Host Off-Line
ONLINEFAILED 43 U1 This variable controls the entry state resulting from a
failed attempt to go On-Line. The two values are:
1 - Equipment Off-Line
3 - Host Off-Line
ONLINESUBSTATE 44 U1 This variable controls the entry state resulting from a
successful attempt to go On-Line. The two values are:
4 - On-Line - Local
5 - On-Line - Remote
OVERWRITESPOOL 62 BOOL This variable enables overwriting the Spool when it
becomes full.
PurgeEnabled 600 BOOL The state of periodic purging operations.
1 - Enabled
0 - Disabled
RPTYPE 17 BOOL This variable enables the Equipment to send annotated
reports to the Host on request.
VisionFailures 112 U4 The number of vision system failures counted by the
FmNT software since the Power On event or latest
Process Program change. The Host may clear this
variable to measure failures during a run.
WBITS10 18 U1 This variable determines the default state of the W bit
for all messages in stream 10 sent from the Equipment
to the Host.
WBITS5 19 U1 This variable determines the default state of the W bit
for all messages in stream 5 sent from the Equipment to
the Host.
WBITS6 20 U1 This variable determines the default state of the W bit
for all messages in stream 6 sent from the Equipment to
the Host.
