Machine Variable Definitions 6-5
Table 6-2 Data Variables (continued)
Variable Name ID Storage
Type
Description
FlowRate2 403 F8 The most current fluid flow rate in mg. per second for
Valve 2.
FlowRateMax1 402 F8 The maximum flow rate in mg./sec. allowed during this
run for Valve 1.
FlowRateMax2 405 F8 The maximum flow rate in mg./sec. allowed during this
run for Valve 2.
FlowRateMin1 401 F8 The minimum flow rate in mg./sec. allowed during this
run for Valve 1.
FlowRateMin2 404 F8 The minimum flow rate in mg./sec. allowed during this
run for Valve 2.
GEMLIMITSVID 57 U4 Contains the VID of the variable whose value crossed
defined limits.
NumFailedBoards 107 U4 The number of boards failed since PwrUp or since the
Process State entered the Running state.
PPCHANGENAME 40 A[0..8] The PPID of the Process Program most recently
changed.
PPCHANGESTATUS 41 U1 The last action performed on the Process Program.
1 - Created
2 - Changed
3 - Deleted
ScaleMeasurement1 406 F8 The actual value read from the scale during a Flow
Rate Verification Procedure when Valve 1 is being
used.
ScaleMeasurement2 407 F8 The actual value read from the scale during a Flow
Rate Verification Procedure when Valve 2 is being
used.
