6-4 Machine Variable Definitions
6.2 Data Variables
Table 6-2 Data Variables
Variable Name ID Storage
Type
Description
ALARMTEXT 1000 A[0..40] The Alarm Text ( ALTX ) for the most recent alarm
transition.
ALARMSEVERITYCODE
1001 B[1] The Severity Code (the low order seven bits) of the
most recent alarm transition.
BarcodeRaw 350 A[30] The barcode string exactly as it is read by the scanner
from the barcode tag on the board at the dispense
station.
BarcodeFiltered 351 A[30] The barcode string read in from the scanner after
unwanted characters are filtered out as specified by
the Operator.
BoardCycleTime 114 U2 The number of seconds required to complete
dispensing an entire board of substrates.
ConveyorSpeed1 500 F4 The Conveyor 1 belt speed during board transfer
between dispensing positions. The units are in./sec.
ConveyorSpeed2 501 F4 The Conveyor 2 belt speed during board transfer
between dispensing positions. The units are in./sec.
ECIDCHANGE 46 U4 The ID of the last event to be reported to the Host.
FluidState1 306 A[10] Fluid level of syringe on Valve 1as reported by the low
fluid sensor or fluid level monitoring software. This
value is updated twice per board. Once when the
board is loaded and ready for dispensing and again
when dispensing is complete on that board. Possible
values are:
“FULL” – Fluid level is full
“LOW” – Fluid level has reached the low level
“EMPTY” – Fluid level is close to empty. This value is
possible only with the two position hardware sensor.
“NONE” – Fluid sensing sensors do not exist or
software monitoring has not been turned on.
“ERROR” – Error when using the two position
hardware sensor. Signals indicate empty but not low.
FluidState2 307 A[10] Same as FluidState1 but for Valve 2.
FlowRate1 400 F8 The most current fluid flow rate in mg. per second for
valve 1.
