Owner's manual

6-2 Machine Variable Definitions
Table 6-1 Status Variables (continued)
Variable Name ID Storage
Type
Description
CLOCK 27 A[16] The current value of the clock accurate to
hundredths of a second. The format is:
YYYYMMDDHHmmsscc.
This format is always the same, regardless of
TIMEFORMAT.
CONTROLSTATE 28 U1 The value indicating the current Control State
Machine state:
1 - OffLine/Equipment OffLine
2 - OffLine/Attempt OnLine
3 - OffLine/Host OffLine
4 - OnLine/Local
5 - OnLine/Remote
DeviceID 115 A[12] The SECS Device ID.
EventLogFilename 104 A[12] The name of the file holding the event log.
EVENTSENABLED 30 List This is the list of events which are enabled for
reporting to the Host.
FluidFileName 300 A[12] The name of the data file holding the dispensing
fluid data. Fluid files have the “.flu” extension.
FluidLotNumber 301 A[20] The lot number of the dispensing fluid.
FluidThawTime 302 A[14] The time stamp, in the YYYYMMDDhhmmss
format, at which the fluid was removed from the
refrigerator and began to warm up.
MachineID 102 A[20] The model number and serial number of the
Asymtek machine. Refer to Appendix A for the
format.
MDLN 31 A[6] The model designation for this machine.
PPDirectory 103 A[30] The directory path of the Process Programs on the
hard disk.
PPEXECNAME 32 A[0..8] The currently selected Process Program ID
number.
PREVIOUSCEID 33 U4 The latest event ID to be sent to the Host.
PREVIOUSCOMMAND 34 A[0..9] The latest remote command received from the
Host.
PREVIOUSCONTROLSTATE 35 U1 The value indicating the previous Control State for
the Equipment:
1 - Off-Line / Equipment Off-Line
2 - Off-Line /Attempt On-Line
3 - Off-Line/Host Off-Line
4 - On-Line Local
5 - On-Line Remote
