Table 5-53 SECS Messages Spooled and Transmitted
Step SECS Message Description
11. H -> E S6F23 W The Host requests that the Equipment continue de-spooling
messages.
12. H <- E S6F24 Equipment indicates that it will start to send spooled messages with
return code RSDA = 0x00. Go to Step 10.
13. H <- E S6F11 W Equipment notifies the Host that sending of spooled messages has
been completed by sending CEID GemSpooling Deactivated.
14. H -> E S6F12 Host acknowledges that the spool has been cleared and is
deactivated.
5.9.3 Host Purges Spool
Assumption: spool state is “Spool Active”
Table 5-54 SECS Messages Host Purges Spool
Step SECS Message Description
1. H -> E S6F23 W Host sends S2F23, requesting that spool be discarded with
RSDC set to one.
2. H <- E S6F24 Equipment deletes spooled data and returns RSDA code zero.
SECS Scenarios 5-25
