5.8 Clock
5.8.1 Host Sets Date and Time
Table 5-49 SECS Messages Host Sets Date and Time
Step SECS Message Description
1. H -> E S2F31 W Date and Time Send. The Host sends a new Date and Time to
the Equipment.
2. H <- E S2F32 The Equipment sets its Clock/Calendar hardware and
acknowledges the command.
5.8.2 Host Requests Date and Time
Table 5-50 SECS Messages Host Requests Date and Time
Step SECS Message Description
1. H -> E S2F17 W Date and Time Request. The Host requests Date and Time
from the Equipment.
2. H <- E S2F18 The Equipment sends its Date and Time.
5.8.3 Equipment Requests Date and Time
Table 5-51 SECS Messages Equipment Requests Date and Time
Step SECS Message Description
1. H <- E S2F17 W Date and Time Request. The Equipment requests Date and
Time from the Host.
2. H -> E S2F18 The Host sends its Date and Time. The Equipment sets its
Clock/Calendar hardware according to the contents of this
message.
