5.6.3 Equipment Sends Text to Host
Table 5-43 SECS Messages Equipment Sends Text to Host
Step SECS Message Description
1. The Operator enters data to send to the Host.
2. H <- E S10F1 [W] Equipment sends text to Host. The W-bit in this message may
be either 0 or 1. The Host displays the message for the
Operator.
3. H -> E S10F2 If the W-bit in S10F1 is 1, the Host acknowledges the text
message.
5.7 SECS Error Messages
5.7.1 Unrecognized Device ID
Table 5-44 SECS Messages Unrecognized Device ID
Step SECS Message Description
1. H -> E SnFn [W] Host sends a message with a bad Device ID in the header. The
W-bit can be either 0 or 1.
2. H <- E S9F1 Equipment replies with “Unrecognized Device ID”.
5.7.2 Unrecognized Stream
Table 5-45 SECS Messages Unrecognized Stream
Step SECS Message Description
1. H -> E SnFn [W] Host sends a primary message with a stream number that the
Equipment does not support. The W-bit can be either 0 or 1.
2. H <- E S9F3 Equipment replies with “Unrecognized Stream”.
5-20 SECS Scenarios
