5.5.5 Host Deletes Process Program
Table 5-38 SECS Messages Host Deletes Process Program
Step SECS Message Description
1. H -> E S7F17 W Host sends a request to delete one or more Process Programs
from the Equipment’s library of Process Programs.
2. H <- E S7F18 The Equipment replies with an acknowledge code. If all
specified Process Program(s) were deleted successfully, the
acknowledge code is 0. If one or more of the specified Process
Programs could not be deleted, the acknowledge code is non-
zero.
5.5.6 Host Requests Directory
Table 5-39 SECS Messages Host Requests Directory
Step SECS Message Description
1. H -> E S7F19 W Host requests the names (PPIDs) of all Process Programs that
are stored in the Equipment’s Process Program library.
2. H <- E S7F20 The Equipment replies with the list of PPIDs.
5.5.7 Operator Changes Process Program Library
Table 5-40 SECS Messages Operator Changes Process Program Library
Step SECS Message Description
1. The Operator creates, changes, or deletes a Process Program
in the Library.
2. H <- E S6F11 W The Equipment sets PPCHANGESTATUS to “Create”,
“Change”, or “Delete”, as appropriate, sets PPCHANGENAME,
and signals CEID GemPPChangeEvent. Event Reports as
appropriate.
3. H -> E S6F12 The Host acknowledges the report.
5-18 SECS Scenarios
