5.3 Alarms
5.3.1 Equipment Reports Alarm
Table 5-21 SECS Messages Equipment Reports Alarm
Step SECS Message Description
1. H <- E S5F1 [W] If reporting for this alarm ID is disabled, skip this and the
following step. Otherwise send the alarm. The equipment
constant “WBitS5” determines whether the W-bit is “0” or “1” in
this message.
2. H -> E S5F2 If the W-bit in S5F1 is 1, the Host acknowledges the alarm
report. Otherwise, skip this step.
3. H <- E S6F11 W If the event ID associated with this alarm state is enabled, send
the Event Report. Otherwise, the scenario ends.
4. H -> E S6F12 The Host acknowledges the Event Report.
5.3.2 Host Enables/Disables Alarms
Table 5-22 SECS Messages Host Enables/Disables Alarms
Step SECS Message Description
1. H -> E S5F3 [W] The Host specifies ALIDs to be enabled or disabled.
2. H <- E S5F4 If the W-bit in S5F3 is 1, the Equipment acknowledges.
5.3.3 Host Requests Alarms
Table 5-23 SECS Messages Host Requests Alarms
Step SECS Message Description
1. H -> E S5F5 W The Host requests whether specified ALIDs are “on” or “off”.
2. H <- E S5F6 The Equipment sends Alarm status.
5-10 SECS Scenarios
