5.2.13 Are You There
Table 5-18 SECS Messages Are You There
Step SECS Message Description
1. H -> E S1F1 W Are You There. The Host sends this simple message.
2. H <- E S1F2 The Equipment reports its MDLN and SOFTREV.
5.2.14 Host Reads Equipment Constants
Table 5-19 SECS Messages Host Reads Equipment Constants
Step SECS Message Description
1. H -> E S2F13 W Host requests the values of one or more equipment constants.
2. H <- E S2F14 The Equipment responds with the values of the requested
equipment constants.
5.2.15 Host Sets Equipment Constants
Table 5-20 SECS Messages Host Sets Equipment Constants
Step SECS Message Description
1. H -> E S2F15 W Host sends new values for one or more equipment constants.
2. H <- E S2F16 If all new values are valid, the Equipment saves the new values
and sends this message with an acknowledge code of “0”. If
one or more new values are not valid, no equipment constants
are changed and the acknowledge code in this message is
non-zero.
SECS Scenarios 5-9
