5.2.10 Host Requests Annotated Report by CEID
Table 5-15 SECS Messages Host Requests Annotated Report by CEID
Step SECS Message Description
1. H -> E S6F17 W Request Annotated Event Report. The Host requests a report
for the specified CEID. In this way, the Host requests the
Equipment to “pretend” that the specified CEID has occurred.
2. H <- E S6F18 The Equipment sends annotated reports linked to that CEID.
5.2.11 Host Requests Report by RPTID
Table 5-16 SECS Messages Host Requests Report by RPTID
Step SECS Message Description
1. H -> E S6F19 W Request Report. The Host requests a report for the specified
RPTID.
2. H <- E S6F20 The Equipment sends the report.
5.2.12 Host Requests Annotated Report by RPTID
Table 5-17 SECS Messages Host Requests Annotated Report by RPTID
Step SECS Message Description
1. H -> E S6F21 W Request Annotated Report. The Host requests an annotated
report for the specified RPTID.
2. H <- E S6F22 The Equipment sends the annotated report.
5-8 SECS Scenarios
