5.2.2 Equipment Reports Event
Table 5-7 SECS Messages Equipment Reports Event
Step SECS Message Description
1. The Equipment recognizes that an event has occurred. The Host
has enabled reporting for the CEID, and possibly has defined one
or more Reports and linked them to the CEID. The equipment
constant “RpType” is set to “False”, requesting normal reports.
2. H <- E S6F5 W Inquire. If S6F13 will be multi-block, the Equipment first sends
this Inquire to request permission. If S6F11 is single-block, skip
this and the next step.
3. H -> E S6F6 Grant. The Host grants permission to send multi-block Event
Report. If GRANT6 is non-zero, this scenario fails here, and the
event data is discarded.
4. H <- E S6F11 W The Equipment sends Event reports for the CEID that occurred
5. H -> E S6F12 The Host acknowledges the report.
5.2.3 Equipment Reports Annotated Event
Table 5-8 SECS Messages Equipment Reports Annotated Event
Step SECS Message Description
1. The Equipment recognizes that an event has occurred. The Host
has enabled reporting for the CEID, and possibly has defined one
or more Reports and linked them to the CEID. The equipment
constant “RpType” is set to “True”, requesting Annotated reports.
2. H <- E S6F5 W Inquire. If S6F13 will be multi-block, the Equipment first sends
this Inquire to request permission. If S6F13 is single-block, skip
this and the next step.
3. H -> E S6F6 Grant. The Host grants permission to send multi-block Event
Report. If GRANT6 is non-zero, this scenario fails here, and the
event data is discarded.
4. H <- E S6F13 W The Equipment sends annotated Event Reports for the CEID that
occurred.
5. H -> E S6F14 The Host acknowledges the report.
"
NOTE In all other scenarios in which Event Reports occur, the Events or Annotated
Events are shown in abbreviated form (S6F11/S6F12 only). The complete Event
Report Scenarios are shown here.
SECS Scenarios 5-5
