5.2 Data Collection
5.2.1 Host Initializes Event Reporting
Table 5-6 SECS Messages Host Initializes Event Reporting
Step SECS Message Description
1. H -> E S2F37 W Disable Event Reports. The Host disables reporting for all
Collection Events.
S2F37 W
<L [2]
<BOOLEAN F>
<L>
> .
2. H <- E S2F38 The Equipment acknowledges. Temporarily, the Equipment
will make no event reports.
3. H ->E S2F33 W Define Report. The Host erases all previous report definitions
and links:
S2F33 W
<L [2]
<U4 DATAID>
<L>
> .
4. H <- E S2F34 The Equipment acknowledges.
5. H -> E S2F33 W Define Report. The Host sends report definitions.
6. H <-E S2F34 The Equipment acknowledges.
7. H -> E S2F35 W Link Events/Reports. The Host links reports to the desired
Collection Events. Linked Reports are initially “disabled”.
8. H <- E S2F36 The Equipment acknowledges.
9. H -> E S2F15 W Equipment constant “Send”. The Host sets equipment
constant “RpType” to indicate whether event reports should be
in “Normal” or “Annotated” format.
10. H <- E S2F16 The Equipment acknowledges.
11. H -> E S2F37 W Enable event reports. The Host enables reporting for desired
collection events.
12. H <- E S2F38 The Equipment acknowledges. From this point on, the
Equipment will report events as they occur.
5-4 SECS Scenarios
