4.2.103 S10F6 - Terminal Display Multiblock Acknowledge
S10F6 * H<-E
<B [1] ACKC10> . * Acknowledge Code
This Equipment may send the following values for ACKC10:
Table 4-34 S10F6 ACKC10 Values
ACKC10 Description
0x00 Normal.
4.2.104 S10F9 - Broadcast
S10F9 [W] * H->E
<A [160] TEXT> . * Message Text
The Host sends text to the Equipment. The Equipment displays the text on its CRT.
The Host may optionally set the W-Bit to “1” in S10F9. If so, the Equipment replies with S10F10.
4.2.105 S10F10 - Broadcast Acknowledge
S10F10 * H<-E
<B [1] ACKC10> . * Acknowledge Code
This Equipment may send the following values for ACKC10:
Table 4-35 S10F10 ACKC10 Values
ACKC10 Description
0x00 Normal.
4-62 Equipment-to-Host Messages
