4.2.95 S9F7 Invalid Data
S9F7 * H<-E
<B [10] MHEAD> . * MHEAD - Header of bad msg
4.2.96 S9F9 Transaction Timer Timeout
S9F9 * H<-E
<B [10] SHEAD> . * SHEAD - Stored Header
4.2.97 S9F11 - Data Too Long
S9F11 * H<-E
<B [10] MHEAD> . * MHEAD - Header of bad msg
4.2.98 S10F1 - Terminal Request
S10F1 [W] * H<-E
<L [2]
<B [1] TID> * Terminal ID
<A [160] TEXT> * Message Text
> .
The Equipment sends text to the Host. This Equipment may send the following values for TID:
Table 4-29 S10F1 TID Values
TID Description
0x00 Always sent.
Equipment constant “WBitS10” controls whether the Equipment sends S10F1 with W-Bit “1” (Reply
Expected) or “0” (No Reply Expected).
Equipment-to-Host Messages 4-59
