4.2.88 S7F17 - Process Program Delete
S7F17 W * H->E
<L
<A PPID> * Process Program ID
...
> .
PPID is the recipe file name and should include the extension RCP.
The Host deletes one or more Process Programs from the Equipment library.
If S7F17 contains a zero-length List, the entire library is deleted.
4.2.89 S7F18 - Process Program Delete Acknowledge
S7F18 * H<-E
<B [1] ACKC7> . * ACKC7 - Acknowledge Code
The Equipment acknowledges the Process Program delete.
Table 4-28 S7F18 ACKC7 Values
ACKC7 Description
0x00 Normal. All specified PPIDs have been deleted.
0x04 Error: At least one specified PPID was not found.
However, correct PPIDs have been deleted from
the Equipment Library.
Equipment-to-Host Messages 4-57
