When the Host sends S7F4, the Equipment interprets ACKC7 as follows:
Table 4-27 S7F4 ACKC7 Interpretations
ACKC7 Description
0x00 Normal.
Other Refusal. The upload operation fails.
4.2.86 S7F5 - Process Program Request
S7F5 W * H<->E
<A PPID> . * Process Program ID
PPID is the recipe file name and should include the extension RCP.
Request the other end of the link to send a specified Process Program from its library.
4.2.87 S7F6 - Process Program Data
S7F6 * H<->E, Multiblock
<L [2]
<A PPID> * Process Program ID
<A PPBODY> * PPBODY - Process Program Body
PPID is the recipe file name and should include the extension RCP.
Send the requested Process Program.
If the specified PPID is not found in the library, S7F6 has the following special format:
S7F6 * H<->E
<L> .
If the Equipment receives S7F6 and cannot store the Process Program in its library, the CEID
BadDownload is signaled, with PPChangeName set to the PPID of the requested Process Program. This
occurs if the received S7F6 is of the special “not found” form, if the S7F6 message is not in the expected
format, or if an error is detected in PPBODY (for example, a parameter out of range).
