4.2.84 S7F3 - Process Program Send
S7F3 W * H<->E, Multiblock
<L [2]
<A PPID> * PPID - Process Program ID
<A PPBODY> * PPBODY – Process Program
Body
PPID is the recipe file name and should include the extension RCP.
Send an Unformatted Process Program. Before sending a multi-block S7F3, the Equipment always first
sends the S7F1/S7F2 Inquire/Grant transaction. The Host may send S7F1/S7F2 before sending S7F3. The
Equipment accepts it, but does not require it.
4.2.85 S7F4 - Process Program Acknowledge
S7F4 * H<->E
<B [1] ACKC7> . * ACKC7
The Receiver acknowledges the receipt of the Process Program. If the transfer succeeds, ACKC7 will
contain 0x00, and the Receiver stores the new Process Program into its library. Any previous Process
Program with the same PPID is deleted. Any non-zero ACKC7 indicates refusal of the Process Program.
When the Equipment sends S7F4, ACKC7 may contain the following codes. Any non-zero code indicates
that S7F3 has not changed the Equipment Library.
Table 4-26 S7F4 ACKC7 Values
ACKC7 Description
0x00 Normal. Process Program Accepted and stored
into Library.
0x01 Permission Not Granted. Insufficient space in
Library.
0x40 Process Program Format Error.
0x41 Process Program Data Error (Verify Failed).
Equipment-to-Host Messages 4-55
