4.2.83 S7F2 - Process Program Load Grant
S7F2 * H<->E
<B [1] 00> . * PPGNT
The Receiver grants permission to send a Process Program. The Receiver sends PPGNT value 0x00 to
indicate it will accept the Process Program, and the Sender should send S7F3. If the Receiver sends any
other value in S7F2, it refuses the Grant, and the Sender should not send S7F3.
The Process Program may be either a Load Recipe, Process Recipe, or Parameter Table.
When the Equipment sends S7F2, PPGNT may contain the following codes:
Table 4-24 S7F2 PPGNT Values
PPGNT Description
0x00 Normal. Permission granted.
When the Host sends S7F2, the Equipment interprets PPGNT as follows:
Table 4-25 S7F2 PPGNT Interpretations
PPGNT Description
0x00 Normal. The Equipment sends S7F3.
Other Refusal. The Equipment does not send
S7F3 and the upload operation fails.
