4.2.81 S6F24 - Request Spooled Data Acknowledge
S6F24 * H <- E
<B [1] RSDA> .
Equipment acknowledges the Host’s request to either purge spooled messages or send spooled messages
to the Host.
Table 4-23 RSDA Values
RSDA Description
0x00 Normal. Equipment will start to send spooled data
or optionally purge the spool. Action performed
will depend on value for RSDC in S6F23.
0x02 Denied. Spooled data does not exist.
4.2.82 S7F1 - Process Program Load Inquire
S7F1 W * H<->E
<L [2]
<A PPID> * Process Program ID
<U4 LENGTH> * Length of text
> .
PPID should be the recipe file name and should include the extension RCP.
The Sender requests permission to send a Process Program. The Process Program may be either a Load
Recipe or Process Recipe.
The Equipment always sends this Inquire/Grant transaction before sending any multi-block S7F3.
LENGTH specifies the number of bytes in the following S7F3 message, excluding SECS-I block-length
bytes, block headers, and checksums.
For Host-to-Equipment transfers, this Inquire/Grant is optional. The Equipment accepts it, but ignores it,
commits no resources, and initiates no Conversation timeout. The Equipment will accept a multi-block
S7F3 even if not preceded by the Inquire/Grant.
Equipment-to-Host Messages 4-53
