4.2.79 S6F22 - Request Annotated Report Data
S6F22 * H<-E, Multiblock
<L
<L [2]
<U4 VID> * VID - Variable ID
<V>
>
...
> .
The Equipment sends the Annotated Report.
If no Report is defined for the RPTID in S6F21, S6F22 has the following special error format:
S6F22 * H<-E
<L> .
4.2.80 S6F23 - Request Spooled Data
S6F23 W * H -> E
<U1 RSDC> .
The Host sends this message to start the transfer of spooled messages from the Equipment to the Host, or
to delete the contents of the spool file, depending on the value of RSDC.
When the Host requests the spooled messages (RSDC is zero), the Equipment will send messages
according to EC “MaxSpoolTransmit”. All messages are sent from oldest to newest, and once the
message is successfully sent, it is removed from the spool. If MaxSpoolTransmit is zero, all messages will
be sent one at a time until the last message has been delivered. If MaxSpoolTransmit is set to a non-zero
value, the Equipment will send the lesser of MaxSpoolTransmit or messages left in spool. If in this case
the Equipment sends MaxSpoolTransmit messages, and messages remain in the spool, the Equipment will
wait for another S6F23 to deliver the next messages.
If the Host sends S6F23 with RSDC set to one, this will be interpreted by the Equipment as a request to
purge the spool.
Table 4-22 RSDC
RSDC Description
0 Transmit spooled messages.
1 Purge spooled messages
4-52 Equipment-to-Host Messages
