4-44 Equipment-to-Host Messages
4.2.63 S6F4 - Annotated Event Report Acknowledge
S6F4 * H->E
<B [1] 00> . * ACKC6
The Host acknowledges the Event Report. The Equipment ignores ACKC6.
4.2.64 S6F5 - Multi-Block Data Send Inquire
S6F5 W * H<-E
<L [2]
<U4 DATAID> * DATAID
<U4 DATALENGTH>
> .
The Equipment sends this Inquire/Grant transaction preceding any multiblock S6F3, S6F9, S6F11, or
S6F13.
The DATAID specified here will appear in the following S6F3, S6F9, S6F11, S6F13.
DATALENGTH value is the total number of text bytes (excluding SECS block headers) in the following
S6F3, S6F9, S6F11, or S6F13 message.
4.2.65 S6F6 - Multi-Block Grant
S6F6 * H->E
<B [1] GRANT6> . * GRANT6
The Host grants permission for the Equipment to send a multi-block Event Report.
Table 4-21 Multi-Block Event Values
GRANT6 Description
0x00 Normal. Permission granted.
Other Permission not granted. The Equipment will not
send the following S6F3, S6F9, S6F11, or
S6F13, and will discard the data.
