4.2.51 S5F4 - Enable/Disable Alarm Acknowledge
S5F4 * H<-E
<B [1] ACKC5> . * ACKC5 - Acknowledge Code
Table 4-20 ACKC5 Values
ACKC5 Description
0x00 Normal. Everything correct.
0x01 Invalid ALID.
4.2.52 S5F5 - List Alarms Request
S5F5 W * H->E
<U4 ALID ...> . * Alarm ID Array
The Host requests the Equipment to send the current status of the specified Alarm IDs.
The Host can use the following special format to request the status of all Alarm IDs:
S5F5 W
<U4>. * ALID
4.2.53 S5F6 - List Alarm Data
S5F6 * H<-E, Multiblock
<L
<L [3]
<B [1] ALCD> * ALCD - Alarm On/Off and Severity Code
<U4 ALID> * Alarm ID
<A ALTX> * ALTX - Alarm Text
>
...
> .
The high-order bit of ALCD will be “1” if this alarm is currently On (Unsafe), or “0” if it is currently Off
(Safe). The low-order seven bits of ALCD contain the severity code for this alarm.
4-38 Equipment-to-Host Messages
