4.2.49 S5F2 - Alarm Acknowledge
S5F2 * H->E
<B [1] 00>. * ACK5 - Alarm Acknowledge
The Host acknowledges the Alarm Report. This Equipment ignores the ACKC5.
4.2.50 S5F3 - Enable/Disable Alarm Send
S5F3 [W] * H->E
<L [2]
<B [1] ALED> * ALED - Alarm Enable/Disable Code
<U4 ALID> * ALID - Alarm ID
> .
The Host commands the Equipment to enable or disable (depending on ALED) reporting for the specified
Alarm ID in S5F1, S5F8, S5F71, and S5F73.
Table 4-19 ALED Values
ALED Description
0x80 Enable sending alarm.
0x00 Disable sending alarm.
The following special format can be used to enable or disable all ALIDs.
S5F3 [W] * H->E
<L [2]
<B [1] ALED> * ALED - Alarm Enable/Disable Code
<U4> * ALID - Alarm ID
> .
The Host may optionally set the W-Bit to “1” in S5F3. If so, the Equipment replies with S5F4.
