4.2.35 S2F36 - Link Event Report Acknowledge
S2F36 * H<-E
<B [1] LRACK> . * LRACK - Acknowledge Code
Normally, LRACK is zero. Any non-zero LRACK indicates the Equipment has rejected the entire S2F35
message.
Table 4-9 LRACK Values
LRACK Description
0x00 OK.
0x02 Denied. Invalid format.
0x03 Denied. At least one CEID link already defined.
0x04 Denied. At least one CEID does not exist.
0x05 Denied. At least one RPTID does not exist.
Other Equipment has rejected the S2F35 message.
4-22 Equipment-to-Host Messages
