4-20 Equipment-to-Host Messages
4.2.33 S2F34 - Define Report Acknowledge
S2F34 * H<-E
<B [1] DRACK> . * DRACK - Acknowledge Code
Normally, DRACK is zero. Any non-zero DRACK indicates the Equipment has rejected the entire S2F33
message.
Table 4-8 DRACK Values
DRACK Description
0x00 OK.
0x02 Denied. Invalid format.
0x03 Denied. At least one RPTID already defined.
0x04 Denied. At least one VID does not exist.
