4.2.29 S2F30 - Equipment Constant Namelist Reply
S2F30 * H<-E, Multiblock
<L
<L [6]
<U4 VID> * Equipment Constant ID
<A ECNAME> * Equipment Constant Name
<ECMIN> * ECV Minimum Value
<ECMAX> * ECV Maximum Value
<ECDEF> * ECV Default Value
<A UNITS> * Units of Measure
>
...
> .
The Equipment returns the equipment constant descriptions in the order requested in S2F29. If any VID
specified in S2F29 is invalid, the corresponding List in S2F30 has the following error format:
<L> * Instead of L [6]
4.2.30 S2F31 - Date and Time Send
S2F31 W * H->E
* T IM E - Date and Time
<A ‘YYMMDDhhmmss’> . * If TIMEFORMAT = 0
- OR -
<A ‘YYYYMMDDhhmmsscc’> . * If TIMEFORMAT = 1
The Host commands the Equipment to set its Date and Time base to the specified value.
When the Equipment receives a good S2F31, it sets its internal clock/calendar. When receiving S2F31,
the Equipment will discard an invalid date or time. For example, if the date is good but the time is bad,
the Equipment sets its date but not its time.
4.2.31 S2F32 - Date and Time Acknowledge
S2F32 * H<-E
<B [1] TIACK> . * TIACK - Acknowledge Code
Table 4-7 TIACK
TIACK Description
0x00 Normal. Everything correct.
0x01 Invalid Date and/or Time.
4-18 Equipment-to-Host Messages
