4.2.27 S2F28 - Initiate Process Acknowledge
S2F28 * H<-E
<B [1] CMDA> . * Command Ack. Code
Normal completion returns a zero (0) in CMDA.
A non-zero value for CMDA indicates that the Equipment has rejected the Remote Command.
Table 4-6 CMDA Values
CMDA Description
0x00 OK. All normal.
0x01 Invalid command. Equipment rejects command.
0x02 Cannot perform now. Equipment rejects command.
0x40 Control State is Local. Equipment rejects command.
0x41 Incorrect Process State for this command.
Equipment rejects command.
0x42 Process program format error.
4.2.28 S2F29 - Equipment Constant Namelist Request
S2F29 W * H->E
<L
<U4 VID> * Equipment Constant ID
...
> .
The Host requests format descriptions for the specified equipment constants. Several VIDs can be
specified if desired.
Only VIDs of class EC (i.e. equipment constants) can be used in this message.
If S2F29 contains a zero-length list, then the Equipment will report all variables of class EC, in order
by VID.
Equipment-to-Host Messages 4-17
